High-Temp Version – 105°C rated
Key Applications:
Material:Tinned copper (24AWG)
Construction:11/0.16mm strands
Count:10-80 conductors
Resistance:≤40Ω/km per conductor
Reinforced polyester film:
Optional:
Fiberglass reinforcement
Kevlar strength members
600V AC/DC
2500V dielectric withstand
PVC insulation (0.3mm)
105°C rated material
Flame-retardant to VW-1
Insulation resistance:>500MΩ
Capacitance:40pF/m max
Operating:-40°C to +105°C
Storage:-50°C to +110°C
UL3173 Specifications Sheet Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 26 7/0.160 0.48 0.76 2.10
UL3265 Specifications Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 32 7/0.080 0.24 0.26 0.80 596 1500 30
UL3266 Specifications Sheet Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 30 7/0.100 0.30 0.38 1.10 381 2000
Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 32 7/0.080 0.24 0.20 0.65 596 500 30 7/0.100
