Zero Toxicity · Precision Wiring · Industrial Toughness
Self-Extinguishing in 3s
UL VW-1 flame test certified, <15% smoke density (IEC 61034) for control panels & robotics.
Halogen-Free & RoHS 3
0ppm chlorine/bromine emissions, compliant with EU Directive 2011/65/EU.
600V Voltage Master
Stable at -40°C to +105°C, ideal for EV charging modules & PLC systems.
Abrasion-Proof Jacket
3X longer lifespan than PVC wires (EN 50396 tested), resists oils and solvents.
Ultra-Pure Tinned Copper Core
Material: 99.97% electrolytic copper with 3μm tin coating (IEC 60228 Class 5)
Sizes: AWG 32 (0.03mm²) to AWG 8 (8.37mm²)
Flexibility: 65 bends/inch without fracture (ASTM B1/B3 tested)
Reinforced Interlayer Protection
Layer 1: Mylar polyester film (0.025mm) for dielectric strength
Layer 2: Aramid fiber braid (200D) for tensile reinforcement
Function: Prevents conductor migration in high-vibration environments
600V AC/DC Continuous Operation
Surge Capacity: Withstands 3kV transient spikes (UL 1581 Section 900)
Key Application: Motor control panels, EV onboard chargers
Dual-Layer Flame Defense
| Layer | Material | Certification |
| Insulation | Cross-linked polyolefin (XLPO) | UL 758 QPLJ8.E12345 |
| Jacket | Halogen-free thermoplastic elastomer (TPE) | IEC 60754-1 (pH >6.0) |
| Performance | Self-extinguishing in 3s (UL VW-1) | Smoke density <15% (IEC 61034-2) |
Engineered to Endure
| Challenge | Performance | Test Standard |
| Abrasion | 30,000+ cycles (1kg load) | EN 50396 |
| Chemicals | Resists oil/IPA/diesel (72h immersion) | ISO 1817 |
| Heat Aging | 7-day @ 136°C with <20% conductivity loss | UL 1581 Sec. 470 |
| Flame | Vertical flame spread ≤50mm | IEC 60332-1-2 |
-40°C to +105°C Operational
Cold Flexibility: No cracking at -55°C (MIL-W-16878/4)
Heat Resistance: 30-minute survival @ 150°C (short-circuit conditions)
UL4348 Specifications Sheet Pitch (mm) Conductor Insulation Resistance At 20C Ω/km Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia. (mm) (No.) Thickness (mm) O.D (mm)
Custom Cable Harnesses with UL/VDE Certification – Precision Engineered for Global Compliance
Custom Wire Harness Solutions – Wire Specification Table Conductor Insulation Max Resistance (Ω/km, 20°C) Dielectric Strength (VAC, 1min) Size (AWG): Custom (40-4/0) Material: Silicone, PVC, TPE, XLPE,
Automotive Standard Wire Harness Specifications Conductor Insulation Max Resistance (Ω/km, 20°C) Dielectric Strength (VAC, 1min) Size (AWG): 8-20 Material: XLPE Construction: Thickness: 0.6-1.0mm 133/0.3mm (8AWG) O.D: 4.5-8.2mm ≤2.1 (8AWG)
