Built to Withstand Harsh Environments
Key Features:
Why Choose Us?
Cut downtime by 30% with harnesses rated for -40°C to 105°C and certified for UL/CE/ATEX.
Tinned copper (19/0.16mm to 19/0.41mm strands)
AWG 24 to 12 for power/signal applications
Aluminum mylar tape + 85% braided shield
Drain wire for proper grounding
600V AC (UL/CSA)
1000V surge protection
Oil-resistant PUR (polyurethane) outer jacket
Dual-layer insulation (XLPE inner + PVC outer)
Tinned copper for corrosion resistance
UL/ATEX dual-certified
500V megger test compliant
Chemical resistance: IP69K rating
-40°C to +105°C flexible
Short-term +150°C peak
UL3173 Specifications Sheet Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 26 7/0.160 0.48 0.76 2.10
UL3265 Specifications Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 32 7/0.080 0.24 0.26 0.80 596 1500 30
UL3266 Specifications Sheet Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 30 7/0.100 0.30 0.38 1.10 381 2000
Conductor Insulation Maximum Conductor Resistance (Ω/Km,20℃) Dielectric Strength (Vac,1min) Size (AWG) Construction (No/mm) Dia (mm) Thickness (mm) O.D (mm) 32 7/0.080 0.24 0.20 0.65 596 500 30 7/0.100
